Hafco Pillar Mill Drill

Description

Under offer

The belt driven head provides a useful range of 12 speeds, 100-2080rpm and is quiet in operation, the head can be re-positioned on the column with the aid of a handle driven rack and pinion drive.
The table has T slots to allow the work to be directly mounting to table, or in a milling vice, with two large diameter control hand wheels with metric calibrations for the longitudinal axis.
The fine downfeed control can be locked firmly in position when milling and the mill also features an easy-to-read depth stop.

Features

• Quiet B section belt drive system
• Milling head rotates 360º on column
• Extra large 820 x 240mm ground work table with T-slots
• Adjustable leadscrew nuts eliminating backlash on both axis
• Fine feed hand wheel operating quill feed
• Digital Readout X/Y Axis’
• Vertex vice with rotating base
• Forward and reverse on/off switch with emergency stop
• 3MT spindle with 75mm diameter quill
• Adjustable table and drill length stops
• Rack and pinion wind-up head
• Rear slide-way cover and slide clamps on all axis
• Spindle lock for quill
• Table locks on both axis
